Emmeline I 34in
From: $851.00
Technical specs at 3 sections long:
| Length | Heat output (Hydronic) | ||
| Height | Heat output (Steam) | ||
| Depth | Delivered in |
- Available from 3 to 40 sections long (see below for technical specs)
- Delivered ready to install up to 10 sections
- Partial home assembly required for larger radiators
- Heat pump compatible
- 25 year warranty
- Made in England
Model Specifications
| Label | Attribute | Value |
|---|---|---|
| A | Height With Legs | 34.1 in |
| B | Bottom Inlet To Floor | 3.9 in |
| C | Max Section Depth | 4.3 in |
| D | Interaxis Distance | 28.5 in |
| E | Height Without Legs | 31.8 in |
| F | Section Length | 2.6 in |
| G | Mid Section Depth | 3.5 in |
| - | Internal Volume | 0.05 gal |
| - | Empty Leg Section Weight | 14.11 lb |
| - | Empty Mid Section Weight | 13.45 lb |
| - | Heating medium | Hydronic, One-pipe steam, Two-pipe steam |
| - | EDR Per Section | 2.16 ft² |
| - | Hydronic Output (170ºF) | 324 BTUs |
| - | Steam Output (215ºF) | 519 BTUs |
Sizes Available
| SKU | N Secs |
Length (L, mm) |
Output (Hydronic, 170ºF) |
Output (Steam, 215ºF) |
EDR | Delivery pieces |
Price from |
|---|---|---|---|---|---|---|---|
| CI-EML1-865-3 | 3 | 9.0 in | 972 BTUs | 1557 BTUs | 6.5 ft² | 3 | $851.00 |
| CI-EML1-865-4 | 4 | 11.7 in | 1296 BTUs | 2076 BTUs | 8.6 ft² | 2 | $943.00 |
| CI-EML1-865-5 | 5 | 14.3 in | 1620 BTUs | 2595 BTUs | 10.8 ft² | 2 | $1,035.00 |
| CI-EML1-865-6 | 6 | 16.9 in | 1944 BTUs | 3114 BTUs | 13.0 ft² | 3 | $1,127.00 |
| CI-EML1-865-7 | 7 | 19.5 in | 2268 BTUs | 3633 BTUs | 15.1 ft² | 3 | $1,219.00 |
| CI-EML1-865-8 | 8 | 22.1 in | 2592 BTUs | 4152 BTUs | 17.3 ft² | 2 | $1,311.00 |
| CI-EML1-865-9 | 9 | 24.7 in | 2916 BTUs | 4671 BTUs | 19.4 ft² | 2 | $1,403.00 |
| CI-EML1-865-10 | 10 | 27.4 in | 3240 BTUs | 5190 BTUs | 21.6 ft² | 1 | $1,415.00 |
| CI-EML1-865-11 | 11 | 30.0 in | 3564 BTUs | 5709 BTUs | 23.8 ft² | 3 | $1,587.00 |
| CI-EML1-865-12 | 12 | 32.6 in | 3888 BTUs | 6228 BTUs | 25.9 ft² | 3 | $1,679.00 |
| CI-EML1-865-13 | 13 | 35.2 in | 4212 BTUs | 6747 BTUs | 28.1 ft² | 3 | $1,771.00 |
| CI-EML1-865-14 | 14 | 37.8 in | 4536 BTUs | 7266 BTUs | 30.2 ft² | 1 | $1,783.00 |
| CI-EML1-865-15 | 15 | 40.4 in | 4860 BTUs | 7785 BTUs | 32.4 ft² | 1 | $1,875.00 |
| CI-EML1-865-16 | 16 | 43.1 in | 5184 BTUs | 8304 BTUs | 34.6 ft² | 3 | $2,047.00 |
| CI-EML1-865-17 | 17 | 45.7 in | 5508 BTUs | 8823 BTUs | 36.7 ft² | 1 | $2,059.00 |
| CI-EML1-865-18 | 18 | 48.3 in | 5832 BTUs | 9342 BTUs | 38.9 ft² | 1 | $2,151.00 |
| CI-EML1-865-19 | 19 | 50.9 in | 6156 BTUs | 9861 BTUs | 41.0 ft² | 3 | $2,323.00 |
| CI-EML1-865-20 | 20 | 53.5 in | 6480 BTUs | 10380 BTUs | 43.2 ft² | 1 | $2,335.00 |
| CI-EML1-865-21 | 21 | 56.1 in | 6804 BTUs | 10899 BTUs | 45.4 ft² | 3 | $2,507.00 |
| CI-EML1-865-22 | 22 | 58.8 in | 7128 BTUs | 11418 BTUs | 47.5 ft² | 3 | $2,599.00 |
| CI-EML1-865-23 | 23 | 61.4 in | 7452 BTUs | 11937 BTUs | 49.7 ft² | 1 | $2,611.00 |
| CI-EML1-865-24 | 24 | 64.0 in | 7776 BTUs | 12456 BTUs | 51.8 ft² | 2 | $2,783.00 |
| CI-EML1-865-25 | 25 | 66.6 in | 8100 BTUs | 12975 BTUs | 54.0 ft² | 2 | $2,875.00 |
| CI-EML1-865-26 | 26 | 69.3 in | 8424 BTUs | 13494 BTUs | 56.2 ft² | 3 | $2,967.00 |
| CI-EML1-865-27 | 27 | 71.9 in | 8748 BTUs | 14013 BTUs | 58.3 ft² | 1 | $2,979.00 |
| CI-EML1-865-28 | 28 | 74.5 in | 9072 BTUs | 14532 BTUs | 60.5 ft² | 3 | $3,151.00 |
| CI-EML1-865-29 | 29 | 77.1 in | 9396 BTUs | 15051 BTUs | 62.6 ft² | 3 | $3,243.00 |
| CI-EML1-865-30 | 30 | 79.7 in | 9720 BTUs | 15570 BTUs | 64.8 ft² | 3 | $3,335.00 |
| CI-EML1-865-31 | 31 | 82.3 in | 10044 BTUs | 16089 BTUs | 67.0 ft² | 3 | $3,427.00 |
| CI-EML1-865-32 | 32 | 85.0 in | 10368 BTUs | 16608 BTUs | 69.1 ft² | 1 | $3,439.00 |
| CI-EML1-865-33 | 33 | 87.6 in | 10692 BTUs | 17127 BTUs | 71.3 ft² | 1 | $3,531.00 |
| CI-EML1-865-34 | 34 | 90.2 in | 11016 BTUs | 17646 BTUs | 73.4 ft² | 3 | $3,703.00 |
| CI-EML1-865-35 | 35 | 92.8 in | 11340 BTUs | 18165 BTUs | 75.6 ft² | 1 | $3,715.00 |
| CI-EML1-865-36 | 36 | 95.4 in | 11664 BTUs | 18684 BTUs | 77.8 ft² | 1 | $3,807.00 |
| CI-EML1-865-37 | 37 | 98.0 in | 11988 BTUs | 19203 BTUs | 79.9 ft² | 2 | $3,979.00 |
| CI-EML1-865-38 | 38 | 100.7 in | 12312 BTUs | 19722 BTUs | 82.1 ft² | 2 | $4,071.00 |
| CI-EML1-865-39 | 39 | 103.3 in | 12636 BTUs | 20241 BTUs | 84.2 ft² | 1 | $4,083.00 |
| CI-EML1-865-40 | 40 | 105.9 in | 12960 BTUs | 20760 BTUs | 86.4 ft² | 1 | $4,175.00 |
