Mercury 4 Column 34in
From: $0.00
Technical specs at 3 sections long:
| Length | Heat output (Hydronic) | ||
| Height | Heat output (Steam) | ||
| Depth | Delivered in |
- Available from 3 to 40 sections long (see below for technical specs)
- Partial home assembly required for larger radiators
- Heat pump compatible
- 25 year warranty
- Made in England
Model Specifications
| Label | Attribute | Value |
|---|---|---|
| A | Height With Legs | 33.9 in |
| B | Bottom Inlet To Floor | 3.9 in |
| C | Max Section Depth | 5.5 in |
| D | Interaxis Distance | 28.5 in |
| E | Height Without Legs | 31.4 in |
| F | Section Length | 2.3 in |
| G | Mid Section Depth | 5.5 in |
| - | Internal Volume | 0.26 gal |
| - | Empty Leg Section Weight | 16.98 lb |
| - | Empty Mid Section Weight | 15.21 lb |
| - | EDR Per Section | 2.91 ft² |
| - | Hydronic Output (170ºF) | 101 BTUs |
| - | Steam Output (215ºF) | 134 BTUs |
Sizes Available
| SKU | N Secs |
Length (L, mm) |
Output (Hydronic, 170ºF) |
Output (Steam, 215ºF) |
EDR | Delivery pieces |
Price from |
|---|---|---|---|---|---|---|---|
| CI-M4C-860-3 | 3 | 8.0 in | 302 BTUs | 402 BTUs | 8.7 ft² | 3 | $0.00 |
| CI-M4C-860-4 | 4 | 10.4 in | 403 BTUs | 536 BTUs | 11.6 ft² | 3 | $0.00 |
| CI-M4C-860-5 | 5 | 12.6 in | 504 BTUs | 670 BTUs | 14.6 ft² | 3 | $0.00 |
| CI-M4C-860-6 | 6 | 14.9 in | 605 BTUs | 804 BTUs | 17.5 ft² | 3 | $0.00 |
| CI-M4C-860-7 | 7 | 17.2 in | 705 BTUs | 938 BTUs | 20.4 ft² | 1 | $0.00 |
| CI-M4C-860-8 | 8 | 19.5 in | 806 BTUs | 1072 BTUs | 23.3 ft² | 2 | $0.00 |
| CI-M4C-860-9 | 9 | 21.8 in | 907 BTUs | 1206 BTUs | 26.2 ft² | 1 | $0.00 |
| CI-M4C-860-10 | 10 | 24.1 in | 1008 BTUs | 1340 BTUs | 29.1 ft² | 2 | $0.00 |
| CI-M4C-860-11 | 11 | 26.4 in | 1108 BTUs | 1474 BTUs | 32.0 ft² | 3 | $0.00 |
| CI-M4C-860-12 | 12 | 28.7 in | 1209 BTUs | 1608 BTUs | 34.9 ft² | 3 | $0.00 |
| CI-M4C-860-13 | 13 | 31.0 in | 1310 BTUs | 1742 BTUs | 37.8 ft² | 3 | $0.00 |
| CI-M4C-860-14 | 14 | 33.3 in | 1411 BTUs | 1876 BTUs | 40.7 ft² | 1 | $0.00 |
| CI-M4C-860-15 | 15 | 35.6 in | 1511 BTUs | 2011 BTUs | 43.7 ft² | 1 | $0.00 |
| CI-M4C-860-16 | 16 | 37.9 in | 1612 BTUs | 2145 BTUs | 46.6 ft² | 3 | $0.00 |
| CI-M4C-860-17 | 17 | 40.2 in | 1713 BTUs | 2279 BTUs | 49.5 ft² | 3 | $0.00 |
| CI-M4C-860-18 | 18 | 42.5 in | 1814 BTUs | 2413 BTUs | 52.4 ft² | 3 | $0.00 |
| CI-M4C-860-19 | 19 | 44.8 in | 1914 BTUs | 2547 BTUs | 55.3 ft² | 1 | $0.00 |
| CI-M4C-860-20 | 20 | 47.1 in | 2015 BTUs | 2681 BTUs | 58.2 ft² | 3 | $0.00 |
| CI-M4C-860-21 | 21 | 49.4 in | 2116 BTUs | 2815 BTUs | 61.1 ft² | 2 | $0.00 |
| CI-M4C-860-22 | 22 | 51.7 in | 2217 BTUs | 2949 BTUs | 64.0 ft² | 1 | $0.00 |
| CI-M4C-860-23 | 23 | 53.9 in | 2317 BTUs | 3083 BTUs | 66.9 ft² | 2 | $0.00 |
| CI-M4C-860-24 | 24 | 56.3 in | 2418 BTUs | 3217 BTUs | 69.8 ft² | 1 | $0.00 |
| CI-M4C-860-25 | 25 | 58.5 in | 2519 BTUs | 3351 BTUs | 72.8 ft² | 3 | $0.00 |
| CI-M4C-860-26 | 26 | 60.8 in | 2620 BTUs | 3485 BTUs | 75.7 ft² | 2 | $0.00 |
| CI-M4C-860-27 | 27 | 63.1 in | 2721 BTUs | 3619 BTUs | 78.6 ft² | 1 | $0.00 |
| CI-M4C-860-28 | 28 | 65.4 in | 2821 BTUs | 3753 BTUs | 81.5 ft² | 2 | $0.00 |
| CI-M4C-860-29 | 29 | 67.7 in | 2922 BTUs | 3887 BTUs | 84.4 ft² | 3 | $0.00 |
| CI-M4C-860-30 | 30 | 70.0 in | 3023 BTUs | 4021 BTUs | 87.3 ft² | 1 | $0.00 |
| CI-M4C-860-31 | 31 | 72.3 in | 3124 BTUs | 4155 BTUs | 90.2 ft² | 1 | $0.00 |
| CI-M4C-860-32 | 32 | 74.6 in | 3224 BTUs | 4289 BTUs | 93.1 ft² | 1 | $0.00 |
| CI-M4C-860-33 | 33 | 76.9 in | 3325 BTUs | 4423 BTUs | 96.0 ft² | 3 | $0.00 |
| CI-M4C-860-34 | 34 | 79.2 in | 3426 BTUs | 4557 BTUs | 98.9 ft² | 3 | $0.00 |
| CI-M4C-860-35 | 35 | 81.5 in | 3527 BTUs | 4691 BTUs | 101.9 ft² | 3 | $0.00 |
| CI-M4C-860-36 | 36 | 83.8 in | 3627 BTUs | 4825 BTUs | 104.8 ft² | 3 | $0.00 |
| CI-M4C-860-37 | 37 | 86.1 in | 3728 BTUs | 4959 BTUs | 107.7 ft² | 3 | $0.00 |
| CI-M4C-860-38 | 38 | 88.4 in | 3829 BTUs | 5093 BTUs | 110.6 ft² | 3 | $0.00 |
| CI-M4C-860-39 | 39 | 90.7 in | 3930 BTUs | 5227 BTUs | 113.5 ft² | 1 | $0.00 |
| CI-M4C-860-40 | 40 | 93.0 in | 4030 BTUs | 5361 BTUs | 116.4 ft² | 1 | $0.00 |
